General Specifications

    Frequency Range (HF Mode): 28.000-29.700 MHz
           (PC Programmable)
    Frequency Range (Export Mode): 25.615-30.105 MHz
            (PC Programmable)
    Frequency Bands A/B/C/D/E/F/G/H/I
    Channel 40 channels (programmable) in each band
    PTT Microphone with UP/DN and coiled cord
    Input voltage 13.8V
    Antenna connector UHF SO239
    Frequency Control Phase-Locked-Loop Synthesizer
    Frequency Step 100Hz/1KHz/10KHz/100KHz/1MHz
    Frequency Tolerance 0.005%
    Frequency Stability 0.001%
    Temperature Range -20c  + 50c

Transmitter Specifications

    Power Output AM: 15W / FM 45W / SSB: 60W(PEP)
    Current Drain 10A (with modulation)
    Unwanted Sideband 50dB
    Frequency Response:
          AM/FM: 300 to 3000Hz *** SSB 450 to 2500Hz
    Output Impedance 50 ohms, unbalanced
    Modulation AM ***FM *** SSB
    Inter-modulation Distortion SSB:
          3rd order, more than -25dB
          5th order, more than -35dB
    SSB Carrier Suppression 55dB

Receiver Specifications

    IF Frequency AM/FM:
          10.695 MHz 1st IF, 455 KHz 2nd IF
           SSB: 10.695MHz
    RF Gain Control 45 dB for optimum signal reception
    Automatic Gain Control:
           Less than 10 dB change from 10 to 100,000 mv
    Squelch Adjustable: threshold less than 1.0µV.
    Automatic Squelch Control(only AM/FM)1.0µV
    Audio Output Power 3 watts into 8 ohms
    Frequency response:
           AM/FM: 300 to 3000 Hz
           SSB 450 to 2500 Hz
    Built-in Speaker 8 ohms, round.
    External Speaker Jack
    Sensitivity SSB: 0.25µV *** AM:1.0 µV *** FM: 1.0µV
    Adjacent-Channel Selectivity:
            AM/FM: 60dB *** SSB: 70dB
    Image Rejection: More than 65 dB
